BittWare Partner Framework

nxFramework

Low-Latency Development Framework

The Enyx Development Framework (nxFramework) is a hardware and software development environment designed to efficiently build and maintain ultra-low latency FPGA applications for the financial industry. Based on 10 years of research and development, nxFramework is the foundation for all Enyx off-the-shelf solutions and provides clients with the toolchain to manage a large portfolio of applications.

Developed for building in-house high performance trading engines, order execution systems, pre-trade risk check gateways, and custom projects — any skilled FPGA developer starting a new low latency project, maintaining an existing one, or looking to change platforms can immediately reduce their time-to-production with nxFramework.

Key Features

10G MAC/PCS @
29ns RTT

10G TCP @
53ns RTT

Library of
60+ utility cores

Features

Ultra-low latency connectivity cores

  • 10G MAC/PCS – 29ns RTT – SOP to SOF @ 322MHz
  • 40G MAC/PCS – 55ns RTT – SOP to SOF @ 322MHz
  • 10G TCP stack – 53ns RTT @ 322MHz
  • 10G UDP stack – 43ns RTT @ 322MHz
  • PCIe streaming DMA – 790ns RTT @ 250MHz

Library of 60+ utility cores

  • MMIO core library
  • Packet streaming core library
  • Memory management core library
  • Math core library
  • Statistics core library
  • Simulation helpers library

Enyx Development Framework Overview

NVMe Bridge Platform IP Core Facts

Provided with Core

  • Documentation: comprehensive user documentation
  • Design file formatsEncrypted Verilog
  • Constraints files: Provided per FPGA
  • Verification: ModelSim verification model
  • Instantiation templates: Verilog (VHDL wrappers available)
  • Reference designs and application notes:  Synthesis and place and route scripts
  • Additional items: Reference design

Simulation tool used:
QuestaSim (contact IntelliProp for latest versions supported)

Support:
Phone and email support will be provided for fully licensed cores for a period of 6 months from the delivery date.

Notes:
Other simulators are available. Please contact IntelliProp for more information.

Video

View a demo of Arkville 17.05 performance plots.

Block Diagram, Data Sheet and Product Details

Enyx Runtime Software Stack

Enyx Runtime Software Stack

Enables simple configuration and monitoring of Enyx connectivity & utility cores, including interaction with the FPGA application via our C/C++ libraries.

Empty heading

Empty hea

Hardware Development Environment

A Python scripted development environment that enables users to simplify their development cycle and accelerate their time-to-production.

Empty heading

Empty head

The Enyx Inspector: Efficient Debugging

Equipped with a web-based GUI that can configure and monitor the FPGA at runtime, allowing for quick deployment and debug.

Empty heading

Empty head

Detailed Feature List

  • All available Enyx connectivity and utility cores
  • Board management cores:
    • Flash controller support for FPGA bitstreams
    • I²C bus controller for SFP/QSFP communication
    • Configurable instantiation of memory controllers (DDR4, QDR II+)
  • Additional elements included:
    • The Enyx Inspector: a web-based debugging tool
    • Linux drivers & configuration/communication libraries
    • Off-the-shelf, configurable reference designs
    • Support for widely used FPGA families in the financial sector

Reference Examples/Use cases

ULL Tick-to-trade platform

  • Standard reference design for ULL tick-to-trade FPGA trading strategies
  • nxFramework provides all the required hardware & software modules to assist with development
  • Sub 100 ns RTT latency

Pre-trade Risk Check Gateway

  • Standard reference design for risk checks gateway acceleration
  • Two distinct TCP stacks connect respectively to the users and to the exchange
  • Sub 1 µs RTT latency

Compatible FPGA Cards
