One of the main problems when compiling code for FPGA is compile time – the backend compile process required for translating DPC++ code into a timing closed FPGA design implementing the hardware architecture specified by that code can take hours to complete. So, the FPGA development flow has been tailored to minimize full compile runs.

1. The first step is functional validation, where code is checked for correctness using a test bench. This is made using emulation on the development platform – where the code targeting the FPGA is compiled and executed on CPU. That allows for a much faster turnaround time when a bug is found and needs to be fixed. A standard CPU debugger (such as the Intel® Distribution for GDB) can be used for that purpose.
2. Once functional validation is completed, static performance analysis is performed through compiler generated reports. Reports include all the information required for identifying memory, performance, data-flow bottlenecks in the design, as well as suggestions for optimization techniques to resolve the bottlenecks. They also provide area and timing estimates of the designs for the target FPGA.
3. After the results of static analysis are satisfactory, a full compile takes place. The compiler can insert on request profiling logic into the generated hardware; profiling logic generates dynamic profiling data for memory and pipe accesses that can later be used by the Vtune performance analyzer for identifying data pattern dependent bottlenecks that cannot be spotted in any other way.
