IA-720i

PCIe Gen5 Single-Width Card with Data Storage

IA-720i card drawing

Compact Card with the Power of Agilex

The Intel Agilex 7 I-Series FPGAs are optimized for applications that are bandwidth intensive and require high performance processor interfaces.

  • 2nd-Generation HyperFlex Architecture: Up to 40 percent higher performance or up to 40 percent lower total power compared with Stratix 10 FPGAs.
  • 100G Networking and Data Storage: Configurable networking and on-card data storage support the most demanding bandwidth requirements.
  • PCIe Gen5 and CXL Support: Data transfer speeds 2x faster than Gen4, and high-speed interface between CPUs and workload accelerators.

Agilex Acceleration Video

100G Networking and Data Storage

IA-720i provides up to 2x 100G to support demanding bandwidth requirements. Configurable networking support includes hard Ethernet media access control (MAC), physical coding sublayer (PCS), and forward error correction (FEC) for a range of speeds. Two M.2 slots support enterprise SSDs for data storage.

2nd Gen Intel® Hyperflex™ Architecture

Continuous improvements to Intel Hyperflex deliver improved performance compared to Stratix 10 device designs. The 2nd Gen architecture thus greatly improve the productivity of customers and reduce time-to-market.

PCIe Gen5 and CXL

PCIe Gen5 supports data transfer speeds 2x higher than PCIe Gen4, providing greater performance capabilities to developers of PC interconnect, graphics adapters, and chip-level communications. And Compute Express Link (CXL) support enables high-speed, low-latency interface to CPUs.

Need a Price Quote?

PCI Express logo

Generation 5.0

Double the Bandwidth!

Built with the latest PCIe Gen5 interface, the IA-720i can transfer up to twice the bandwidth of Gen4 devices.

Enterprise-class for Deployment

Ramp to product with the power of Molex

The IA-720i is built on BittWare’s enterprise-class foundation stones: existing products and processes that are already proven through extensive validation. When it’s time to ramp to production, this means a faster turnaround and utilizing the same hardware you have been using for development.

BittWare enterprise class categories illustration
MCIO 8x cable

400G Networking

QSFP-DDs provide up to 400Gbps with hard IP for 10/25/100GbE links (up to 4× 100GbE total).

Inquire about customized Molex connectors/cables as required for your application.

Molex QSFP-DD to 4x 100G cable

Flexible IO and Storage

With QSFP56 cages and SSD slots, the IA-720i offers a range of flexibility to meet your application needs:

  • Two QSFP56s provide up to 2x 100G with hard IP for 100/50/25/10 GbE links.
  • Two M.2 slots support enterprise SSDs for data storage. The SSD slots are connected to PCIe hard IP.
CXL logo

Supporting CXL

CXL (Compute Express Link) is an industry-supported cache-coherent interconnect between processors, memory expansion, and accelerators. CXL technology maintains memory coherency between the CPU memory space and memory on attached devices, which allows resource sharing with lower latency, reduced software stack complexity, and lower overall system cost.

* CXL requires licensing that is sold separately from the card

Supporting Intel's oneAPI

Develop faster + reuse code in this software-orientated tool flow

Supporting high-level software tool flows is critical to a growing customer base who want to take advantage of heterogenous architectures. The new oneAPI from Intel is designed around code re-use while providing similar performance to other high-level tools.

BittWare recently completed an updated 2D FFT white paper using oneAPI and found the performance matches our optimized OpenCL-based approach.



IA-720i Block Diagram, Data Sheet and Specifications

Want More Details?

Request the Hardware Reference Guide (HRG)

The HRG gives you much more detail about the card such as block diagrams, tables and descriptions.

Board Specifications

FPGA

  • Intel Agilex 7 I-Series AGI023
    • AGI023: Core speed grade -1: XCVR speed grade -1 for CXL(CXL IP is licensed and purchased separately)
    • FPGA includes ARM HPS

ARM HPS

  • Dedicated 72-bit DDR4
  • Dedicated Flash memory for booting ARM

On-Board flash

  • 2Gbit Flash memory for booting FPGA

External memory

  • 2x 72-bit DDR4 banks, up to 32GB each (64GB total)

M.2 SSD Slots

  • 2x slots for NVMe PCIe M.2 22110 SSDs

Host interface

  • x16 Gen5 interface direct to FPGA, connected to PCIe hard IP
  • CXL support (CXL IP is licensed and purchased separately)

QSFP-DD cages

  • QSFP56 cages supporting a total of 2x 100/50/25/10GbE
  • Multi-rate hard MAC supports all combinations
  • Jitter cleaner for network recovered clocking

GPIO

  • 4x GPIO

External clocking

  • 1 PPS and 10MHz ref clk inputs (in-board)

USB

  • USB access to BMC, USB-UART

Board Management Controller

  • Power sequencing and reset
  • Voltage, current, temperature monitoring
    • Protection shut-down
  • Clock configuration
  • Low bandwidth BMC-FPGA comms with SPI link
  • USB 2.0
  • PLDM support
  • Card-level security
    • BMC Root of Trust
    • BMC and FPGA secure boot
    • BMC and FPGA secure upgrade
    • Key management
  • RTC with battery backup

Cooling

  • Standard: single-width passive heatsink

Electrical

  • On-board power derived from PCIe slot and external power connector
  • Power dissipation is application dependent
  • Max power consumption 150W

Environmental

  • Operating temperature: 5°C to 35°C

Quality

  • Manufactured to IPC-A-610 Class 2
  • RoHS compliant
  • CE, FCC, UKCA & ICES approvals

Form factor

  • Standard-height, 3/4-length, single-slot PCIe card
  • Size: 111.15mm x 254.00mm (4.376in x 10.000in)

Development Tools

System development

  • BittWare SDK including PCIe driver, libraries, and board monitoring utilities

Application development

  • Intel High-Level Synthesis (C/C++) and Quartus Prime Pro (HDL, Verilog, VHDL, etc.)
