PROVA-C Appliance Running GENEM-C Software

PROVA-C Appliance

Runs GENEM-C 100G Network Test Application

4× 100G 1U Appliance Built on BittWare

Built on BittWare

The PROVA-C appliance, running GENEM-C software from Siama, is available as an appliance using enterprise-class FPGA hardware and servers from BittWare.

Siama Systems logo

GENEM-C Key Features

Touch or mouse over an item to learn more

network impairment icon

Wire-Rate Traffic Generator

Wire-Rate Traffic Generator

Synthetic Traffic tool that emulates real-world traffic by combining multiple application streams into multiplexed flows
RFC icon

Wire-Rate Capture Buffer

Wire-Rate Capture Buffer

Wire-Rate 64 GB Capture Buffer per SmartNIC
flow icon

Network Impairment

Network Impairment

Tool that adds latency, jitter and loss between traffic source to simulate network conditions
capture buffer icon

Flow Diagnostics

Flow Diagnostics

Tools to identify and troubleshoot the performance and availability of a service and/or a flow
wire rate icon

RFC 2544

RFC 2544

Methodology to evaluate the Throughput, the Latency, the Frame Loss Rate and the Back to Back Rate
ports icon

QSFP28 Test Ports

QSFP28 Test Ports

Supports 100GBASE-SR4/LR4/ER4

Video

Hear from Siama CTO Marco Mascitto on how GENEM-C is a unique solution.

Web GUI Example Screenshots

Tap to zoom

What is the GENEM-C Application?

It's a 100G network test application to verify, monitor and troubleshoot Ethernet/IP network equipment and data center applications.

The GENEM-C application is designed for the test requirements of network equipment manufacturers, data centers, service provider telco cloud and 5G backhaul. The application runs on the PROVA-C  appliance 1U server with 4× front-panel QSFPs and SMA timing interfaces.

A wide range of test features are available, including Service Activation Testing, Performance Management, and Traffic Generation. Packet filtering, capture and playback are also supported from the FPGA card’s 64GB DDR4 memory. GENEM-C is ideal for QA test and Service Providers migrating to a DevOps model to validate service turn-up and modifications in the production network. GENEM-C is equally at home in a lab environment. It bundles wire-rate traffic generation and analysis capabilities with a network emulator and packet capture/replay function in a single software license.

With GENEM-C, you're getting all the features you expect from a proprietary solution, but at a fraction of the cost.

400 GBPS TEST CAPACITY

100G/25G ETHERNET INTERFACE SUPPORT

WIRE-RATE TRAFFIC GENERATION & CAPTURE

SCALABLE X86 COTS PLATFORM

LINUX® OPERATING SYSTEM

ETHERNET/IP APPLICATION EMULATION

MULTI-FLOW TRAFFIC GENERATION

PERFORMANCE & CONFORMANCE TESTING

PACKET CAPTURE, ANALYSIS & PLAYBACK

NETWORK EMULATION & IMPAIRMENT TOOLS

SERVICE ACTIVATION TESTING

Product Specifications

Service Activation Testing

  • ITU-T Y.1564 testing
    • 16 simultaneous tests
    • Conformance & performance tests
    • Color-aware and color-blind services
    • CBS and EBS testing
  • MEF 46 Latching Loopback
    • Automatically loopback remote end
  • One-way or Two-way performance measurement
  • RFC 2544
    • Layer 2 and Layer 3 testing
    • Throughput
    • Frame loss
    • Latency
    • Back-to-back
  • Export reports in PDF format

Performance Management

  • ITU-T Y.1731 Performance & Fault Management
    • Test 64 simultaneous Ethernet services
    • MEF 35 PM-1 solution
    • DMM for FD and IFDV
    • SLM for loss measures (availability)
    • CCM & LBM for continuity check

Traffic Generation

  • Generate Layer 2 to 4 stateless traffic
  • 64 configurable streams per port
  • Compliant to SFF-86364 flows per test port
  • Create complex traffic patterns and bursts

Packet Filtering & Actions

  • Powerful micro-scan™ engines match incoming packets at line rate
  • Up to 32 match-action filters can be defined per test port
  • Configure actions on matched packets:
    • Loopback modified or unmodified
    • Forward to performance collector
    • Store in capture buffer
    • Forward to another test port
    • Forward to CPU for further processing

Packet Capture & Playback

  • 64GB of onboard capture memory
  • Line-rate capture on each test port simultaneously
  • User-configurable buffer sizes
  • Export buffers in PCAP format
  • Import PCAPs into buffers for replay at captured rate or up to line rate

Network Emulation & Impairment

  • Add delay, jitter and loss to flows
  • Up to 4.8 seconds of delay can be introduced
  • Select from a variety of jitter distribution functions
    • Uniform
    • Normal
    • Exponential
    • Gamma
  • Add periodic or pseudo-random loss

Management

  • Web GUI, HTTPS, TLS1.2
  • SSH access for CLI and LUA Scripting
  • IPv4 and IPv6 support
  • VLAN support
  • Local, RADIUS & TACACS+ User Authentication and Authorization

Test Port PHYs Supported

  • 100GBASE-SR4/LR4/ER4
  • 25GBASE-SR/LR/ER (future release)
