FPGA Server
TeraBox 4000S
4U Server for FPGA Cards
Obsolete Product Notice:
This is an obsolete product and is not intended for new designs. Contact BittWare for a recommended newer product.
Overview
BittWare’s TeraBox-4000S offers a 4U, 8-slot chassis that is ideal for all-around density, CPU power, and yet cost-effectiveness. Configurations include up to 8 of BittWare’s large double-width cards using Achronix Speedster 7t, Intel Stratix 10, or Xilinx Virtex UltraScale+ FPGAs. Users seeking maximum logic/memory density can choose the XUP-VV4 for 30M logic cells and 4TB FPGA-attached DDR4 memory.
Or choose the XUP-VV8, which features QSFP-DDs and yields an impressive 64x 100G — for a port density of 16 per rack unit! No matter which configuration you choose, you’re getting BittWare’s installation and support.
Key Features
Up to
32 QSFPs
for 64x 100G or 256x 10/25G
4U
4U FPGA server
Support for BittWare’s full range of FPGA cards
Up to 8 double-slot FPGA cards can be configured or
8 low-profile cards
Chassis Key Specs
- 4U, depth 29 in (737mm)
- Processor: Intel® Xeon® Scalable processor
- Memory: 24x ECC DDR4-2667 DIMMs
- Slots: 8x double-width PCIe Gen3 x16, 2x PCIe Gen3 x8
- Storage: Up to 10x 2.5” SATA, Intel C622 RAID
- Power supply: 2000W, redundant (2+2), Titanium
FPGA Cards
The TeraBox 4000S is a 4U FPGA server based on the SuperMicro 4029GP-TRT chassis. This server offers two Intel Xeon Scalable CPUs along with high PCIe slot density. With configurations of up to 8 of BittWare’s large double-width cards, this server is an excellent premium option for the 4U form factor.
System Management
For system management, BittWare’s FPGA cards are equipped with a Board Management Controller (BMC), which accepts IPMI 2.0 commands. Use it along with BittWare’s BittWorks II Toolkit to program the FPGA over USB, monitor card power and temperature, and re-program the onboard clocks. You’ll also be able to set points to shut down the card when it gets too hot, access JTAG, or access the software tools remotely.
The TeraBox Advantage
Choosing a TeraBox FPGA server means knowing you are getting a pre-configured and tested solution. This includes setup and installation of your FPGA cards and associated hardware, your choice of operating system, and development tools. Your TeraBox arrives ready for use—giving your team more time for development and deployment.
Data Sheet and Specifications
Certified Cards
The TeraBox 4000S supports many of BittWare’s Achronix, Intel, or Xilinx FPGA-based PCIe cards. The table below lists specifications for some of our certified* cards:
| FPGA | Cards in Server | Memory | I/O | Processing | |
| S7t-VG6 | Speedster7t | 8 | 64 banks GDDR6 (up to 64 GBytes) | 8x QSFP-DD, 8x QSFP28 48x 100/50/40/25/10 GbE |
5.5 million 6-input lookup tables (LUTs) 1.5 Gbits embedded RAM |
| 520N-MX | Stratix 10 MX | 8 | 16 banks DDR4 (up to 2 Terabytes) 32 banks QDRII+ (up to 4.6 Gbits) |
32x QSFP28s 32x 100/50/40/25/10 GbE |
16.8 million system logic elements 128 GBytes HBM2 |
| XUP-VV8 | UltraScale+ VU13P | 8 | 32 banks DDR4 (up to 4 Terabytes) 64 banks QDRII+ (up to 18.4 Gbits) |
32x QSFP-DDs 64x 100/50/40/25/10 GbE |
30.4 million system logic cells Up to 98,304 DSP slices |
* Subject to availability. Contact BittWare for additional FPGA card options.
Server Configurations
Low
- (2) Intel Xeon Bronze 3106 Processors (1.7GHz, 8C/8T)
- 96GB DDR4
- (2) 960GB SSD
- 2000W Redundant Power Supplies
Medium
- ((2) Intel Xeon Silver 4114 Processors (2.2GHz, 10C/20T)
- 96GB DDR4
- (2) 960GB SSD
- 2000W Redundant Power Supplies
High
- (2) Intel Gold 5120 Processors (2.2GHz, 14C/28T)
- 192GB DDR4
- (2) 960GB SSD
- 2000W Redundant Power Supplies
Ultra
- (2) Intel Xeon Platinum 8180 Processors (2.5GHz, 28C/56T)
- 768GB DDR4
- (2) 960GB SSD
- 2000W Redundant Power Supplies
Interested in Pricing or More Information?
Our technical sales team is ready to provide availability and configuration information, or answer your technical questions.
