Xilinx FPGA Platforms - BittWare

Browse Our Products with Xilinx FPGAs

BittWare manufactures a wide range of FPGA PCIe cards and sells a range of compatible IP cores and servers. We provide custom ODM and OEM design services for customers that need specialized solutions in volume (reach out for our volume pricing). Explore our products below!

Filters:

Filter by:

Form Factor

Memory

Networking

IA-865m Card
PCIe Dual Width

Intel Agilex 7 FPGA : AGM032

PCIe Gen5 x16 + CXL

up to 3× QSFP-DD (400G)

MCIO Gen4 x8 (dual x4) expansion

BittWare BMC + SDK

IA-860m Card
PCIe Dual Width

Intel Agilex 7 FPGA : AGM039

PCIe Gen5 x16 + CXL

3× QSFP-DD (400G)

MCIO Gen4 x8 (dual x4) expansion

BittWare BMC + SDK

IA-780i Card
PCIe Single Width

Intel Agilex 7 FPGA : AGI023

PCIe Gen5 x16 + CXL

64GB DDR4 (2x banks)

2× QSFP-DD (400G)

BittWare BMC + SDK

IA-440i Card
PCIe Low Profile

Intel Agilex 7 FPGA : AGI023

PCIe Gen5 x16 + CXL

Up to 32GB DDR4 (2x banks)

1× QSFP-DD (400G)

BittWare BMC + SDK

S7t-VG6 Card
PCIe Full Size, Dual Width

Speedster7t FPGA: AC7t1500

PCIe Gen5 x16

16GB GDDR6 (512 GB/s); 4GB DDR4

1× QSFP-DD (up to 400 GbE); 1× QSFP-56 (up to 200 GbE); 1× MCIO x4 expansion

BittWare BMC, GPIO, 1 PPS/10MHz ref clk

Versal ACAP
Early Access Program

Learn about AMD's next-generation programmable hardware
AMD ACAPs : 7nm

RFX-8440 Card
PCIe Full Size, Dual Width

Zynq UltraScale+ RFSoC : XCZU43

PCIe or Standalone

Flexible 4 Channel Analog In/Out

Up to 200Gbps digital I/O via inboard OCuLink -or- dual QSFP28s
Hard IP: PCIe Gen4 x8 dual 100GbE

Example project; clocking/timing options

IA-840f Card
PCIe Full Size, Dual Width

Intel Agilex 7 FPGA : AGF027

PCIe Gen4 x16

128GB DDR4 (4x banks)

3× QSFPDD (200G); 2× MCIO x8 expansion

BittWare BMC + SDK

IA-420f Card
PCIe Low Profile

Intel Agilex 7 FPGA : AGF014

PCIe Gen4 x16

Up to 32GB DDR4 (2x banks)

1× QSFPDD (200G)

BittWare BMC + SDK

IA-220-U2 Module
U.2 Storage

Intel Agilex 7 FPGA : AGF014

PCIe Gen4 x4 (U.2 interface)

Up to 16GB DDR4 (2x banks)

520N-MX Card
PCIe Full Size, Dual Width

Intel Stratix 10 FPGA : MX2100

PCIe Gen3 x16

16GB on-chip HBM2; 32GB DDR4 or 1,152Mb QDR-II+ (2× banks, up to 256GB DDR4 avail.)

4× QSFP28 (100/40G or 4× 10/25G ea); 2× or 4× OCuLink x8 expansion

BittWare BMC + BIST; OpenCL BSP

520NX Card
PCIe Full Size, Dual Width

Intel Stratix 10 FPGA : NX2100

PCIe Gen3 x16

8GB on-chip HBM2; 32GB DDR4 or 1,152Mb QDR-II+ (2× banks, up to 256GB DDR4 avail.)

4× QSFP28 (100/40G or 4× 10/25G ea); 2× or 4× OCuLink x8 expansion

BittWare BMC + BIST

XUP-VV8 Card
PCIe Full Size, Dual Width

Virtex UltraScale+ FPGA : VU9/VU13P

PCIe Gen3 x16

Up to 512GB DDR4 or 2,304Mb QDR-II+ (4× banks)

4× QSFP-DD (2× 100/40G or 8× 10/25G ea); 2× OCuLink x4 expansion

BittWare BMC; clocking/timing options

XUP-P3R Card
PCIe Full Size, Dual Width

Virtex UltraScale+ FPGA : VU9P

PCIe Gen3 x16

Up to 512GB DDR4 or 2,304Mb QDR-II+ (4× banks)

4× QSFP28 (100/40G or 4× 10/25G ea); SEP x20 + GPIO expansion

BittWare BMC; clocking/timing options; SEP add-on cards available

XUP-VVH Card
PCIe Full Size, Dual Width

Virtex UltraScale+ FPGA : VU37P

PCIe Gen3 x16

8GB on-chip HBM2; Up to 256GB DDR4 or 1,152Mb QDR-II+ (2× banks)

4× QSFP28 (100/40G or 4× 10/25G ea); 2× SlimSAS x8 expansion

XUP-VVP Card
PCIe Full Size, Dual Width

Virtex UltraScale+ FPGA : VU9/VU11/VU13P

PCIe Gen3 x16

Up to 256GB DDR4 or 1,152Mb QDR-II+ (2× banks)

4× QSFP28 (100/40G or 4× 10/25G ea); 2× SlimSAS x8 expansion

BittWare BMC; 300A FPGA core power

XUP-VV4 Card
PCIe Full Size, Dual Width

Virtex UltraScale+ FPGA : VU13P

PCIe Gen3 x16

Up to 512GB DDR4 or 2,304Mb QDR-II+ (4× banks)

4× QSFP28 (100/40G or 4× 10/25G ea); 2× SlimSAS x8 expansion

520R-MX Card
PCIe Full Size, Dual Width

Intel Stratix 10 FPGA : MX2100

PCIe Gen3 x16

16GB on-chip HBM2; 32GB DDR4 or 1,152Mb QDR-II+ or Intel Optane (2× banks, up to 256GB DDR4 avail.)

4× 12-channel 10G optical receivers; 3× OCuLink x4 expansion

BittWare BMC + SDK

520N Card
PCIe Full Size, Dual Width

Intel Stratix 10 FPGA : GX2800

PCIe Gen3 x16

32GB DDR4 (4× banks, 64GB avail.)

4× QSFP28 (100/40G or 4× 10/25G ea)

BittWare BIST; OpenCL BSP

520C Card
PCIe Full Size, Dual Width

Intel Stratix 10 FPGA : GX2800

PCIe Gen3 x16

32GB DDR4 (4× banks, 64GB avail.)

BittWare BIST; OpenCL BSP

510T Card
PCIe Full Size, Dual Width

Dual Intel Arria 10 FPGA : 2× GX1150

PCIe Gen3 x16 (switch)

32GB DDR4 (2× banks per FPGA)

BittWare BIST; OpenCL BSP

XUP-PL4 Card
PCIe Low Profile

Virtex UltraScale+ FPGA : VU3P

PCIe Gen3 x16

32GB DDR4 (2× banks)

2× QSFP28 (100/40G or 4× 10/25G ea)

BittWare BMC; optional timing kit

A10SA4 Card
PCIe Low Profile

Intel Arria 10 FPGA : GX1150

PCIe Gen3 x8

16GB DDR4 (2× banks)

1× QSFP28 (40G or 4× 10G)

BittWare BMC; OpenCL BSP; clocking/timing options

250-SoC Card
PCIe Low Profile

Zynq UltraScale+ MPSoC : ZU19EG

PCIe Gen3 x16

FPGA: 4GB DDR4 (1× bank); ARM: 4GB DDR4 (1× bank)

2× QSFP28 (100/40G or 4× 10/25G ea); 2× or 4× OCuLink x8 expansion

BittWare BIST; optional 1GbE access to ARM

A10PL4 Card
PCIe Low Profile

Intel Arria 10 FPGA : GX1150

PCIe Gen3 x8

32GB DDR4 (2× banks)

2× QSFP28 (40G or 4× 10G ea)

BittWare BMC; OpenCL BSP; optional timing kit

250S+ Card
PCIe Low Profile

Kintex UltraScale+ FPGA : KU15P

PCIe Gen3 x8

8GB DDR4 (1× bank)

385A-SoC Card
PCIe Low Profile

Intel Arria 10 FPGA : SX660

PCIe Gen3 x8

FPGA: 4GB DDR4 (1× bank); ARM: 2GB DDR4 (1× bank)

2× QSFP28 (1× 40G or 4× 10G ea)

385A-SFP Card
PCIe Full Height, Half Length, Single Width

Intel Arria 10 FPGA : GX1150

PCIe Gen3 x8

8GB DDR3 (2x banks; 32GB avail.)

6x SFP+ (1/10G ea)

BittWare BIST; GPIO

385A Card
PCIe Low Profile

Intel Arria 10 FPGA : GX1150

PCIe Gen3 x8

8GB DDR3 (2x banks; 32GB avail.)

2× QSFP28 (1× 40G or 4× 10G ea)

BittWare BIST; OpenCL BSP

250-U2 Module
U.2 Storage

Kintex UltraScale+ FPGA : KU15P

PCIe Gen3 x4 (U.2 interface)

8GB DDR4 (1× bank)
